USB 3.0 HDMI Video Capture Card – 4K Input, 1080p60 & Loop-Out

Bring an HDMI camera, console or media source into your computer for streaming, recording or presentations. This wired USB 3.0 capture device accepts supported HDMI input signals up to 4K and captures to your computer at up to Full HD 1920 × 1080 at 60 fps.

Important resolution note: “4K” refers to compatible HDMI input signals. This device does not capture 4K video. Maximum capture output is 1080p at 60 fps.

Key features

• 4K HDMI input: accepts compatible source signals up to 4K.
• Up to 1080p60 capture: records or streams to a compatible computer and capture application at up to 1920 × 1080, 60 fps.
• HDMI loop-out: connects the incoming source to a compatible monitor or TV while the computer captures the video.
• USB 3.0 host connection: the included USB-A to USB-A cable connects the capture device to a compatible computer USB 3.0 port.
• Separate 3.5 mm audio ports: microphone input plus headphone/audio output for a flexible creator setup.
• Wired aluminium design: compact metal enclosure with no battery, wireless pairing or external power adaptor required.

Connection guide

1. Connect your HDMI source to the capture card’s HDMI input.
2. Optional: connect the HDMI loop-out to a monitor or TV using a separate HDMI cable.
3. Connect the capture card to a compatible computer USB 3.0 port with the included cable.
4. Select the capture device in your compatible recording or streaming application.

What’s included

• 1 × USB 3.0 HDMI video capture device
• 1 × blue USB 3.0 Type-A to Type-A cable

Before you buy

• HDMI cables, microphone, headphones, display and source device are not included.
• Available input modes, capture resolution and frame rate depend on the source device, computer, USB port and software.
• HDR compatibility is not specified. No HDR or zero-latency performance is claimed.
• Use the included USB cable only between this capture device and a compatible computer USB port. Do not use it to connect two host computers.
